DH43H-2MP-W PTZ CAMERA

5X Zoom 1080P PTZ IP Camera White





5x auto focus zoom lens provide detailed view

Patent designed

HD Pan/Tilt/Zoom wireless dome IP camera

H.264/H.265 video compression

Day/Night surveillance, IR LEDs On/Off auto switch

With 22pcs IR-LEDs, night vision range up to 30m

Motion detection alarm via E-mail, upload alarm snapshot to FTP

Compatible with free PC central management software(Device Clients)

Compatible with free iOS and Android APP

Supports IEEE 802.11b/g/n wireless connection

Supports WEP, WPA and WPA2 encryption

P2P feature for easy remote access



Model:

DH43H

Image Sensor

Image Sensor

Color CMOS WXGA(megapixel) HD sensor

Chipset Solution

T31N+SC200AI

Display Resolution

1080p(1920*1080),800*600

Mini. Illumination

0.01Lux

Lens

Lens Type

Glass Lens





Focal Length





2.7-13.5mm 5X Auto Focus Zoom

Aperture

F1.4

Angle of view

92° ~ 28°

Video

Image Compression

H.265, H.264 High Profile ,H.264 Main Profile H.264 Baseline

Image Frame Rate

1080P 20fps(50HZ), 20fps(60HZ)

Stream

Double Stream

Image Adjustment

The brightness, contrast, saturation, chroma are adjustable

Flip Mirror Images

Reversal and mirror

Night visibility

22pcs IR-LEDs, night vision range up to 30m

IR-CUT

Dual IR-CUT filter (Original)

Infrared mode

Automatic or manual

Light Frequency

50Hz, 60Hz

PTZ

Pan/Tilt Angle

Horizontal:355° & Vertical: 75°

3D Preset

8 presets, include Horizontal & Vertical Position and Focal length

Preset Cruise

1-8 preset positions cruise

Border Scan

Set any position as left or right border, scan between the borders

Horizontal Scan

355° horizontal scan

Guard position

Support, default is preset position 1

Alarm preset

Support

ONVIF

ONVIF

Support ONVIF 2.4

Network

Ethernet

10/100Mbps RJ-45 port

Protocol

TCP/IPHTTPTCPICMPUDPARP, IGMPSMTPFTPDHCPDNSDDNSNTPUPNPRTSP

Wireless Standard

IEEE 802.11b/g/n

Data Rate

IEEE802.11b: 11Mbps(Max.)
 IEEE802.11g: 54Mbps(Max.)
 IEEE802.11n: 150Mbps(Max.)

Wireless Security

WEP, WPA, WPA2

System

By PC

Windows XP/7/8/10, Vista, Mac OS

By Phone

Android, iOS

Browser

Microsoft IE7 and above version or compatible browser;
 Mozilla Firefox; Google Chrome; Apple Safari.

Device Clients

Up to 64-channel,centralized monitor, remote record and playback

Physical

Dimension

162(L)*Φ131(W)*191(H) mm

Net/Gross Weight

1200g/1600g

Color Box

235(L) x 165(W) x 215(H) mm

Power

Power Supply

DC 12V/1A

Power Consumption

8 ~12 Watts (Max.)

Other Feature

Protection level

IP65

Shell

Metal shell

User Accounts

administrator

UID Technology

UID scan technology applied, easy to operate, and highly confidential.

Reset

Reset button is available

Alarm

Motion detection alarm

Environment

Operate Temp.

0° ~ 50°C  (32°F ~ 131°F)

Operating Humidity

10% ~ 95% non-condensing

Storage Temp.

0° ~ 50°C  (32°F ~ 131°F)

Storage Humidity

10% ~ 95% non-condensing

Certification

CE, FCC, RoHS

Warranty

Limited 1-year warranty

Operating temperature

0° ~ 50°C  (32°F ~ 131°F)

Package
